The Nocpix Quest H50R redefines portable thermal imaging with exceptional reach and precision. Lightweight and field-ready, the QUEST offers detection up to 2600m and a built-in concealed Laser Rangefinder (LRF) with a 1000m range for superior accuracy and visibility.
Designed for hunters, landholders and pest management professionals, the H50R delivers powerful performance in a compact, one-hand-operable body, combining ergonomic comfort, advanced optics, and AI-driven image enhancement.
Key Features
Lightweight Long-Range Performance
The Quest H50R is lightweight and portable, offering detection up to 2600m and a built-in concealed LRF (1000m range) for pinpoint accuracy in the field. Perfect for open country scanning or precision target identification from a vehicle or tripod.
One-Hand Operation
Operate effortlessly with one hand, just like traditional binoculars. The centrally positioned zoom lever allows smooth adjustment with a single finger, even while wearing gloves. With only four intuitive buttons, users can easily focus, zoom and range with two fingers, simplifying operation and improving efficiency in the field.
Ergonomic Design
The Quest’s binocular-style body fits naturally in hand, ensuring comfort during long observation sessions. Its balanced weight and textured silicone grip make it secure, even in wet or dusty conditions, perfect for field or vehicle use.
Compact and Lightweight
Weighing only 700g and measuring 175×138×66mm, the H50R’s magnesium alloy frame and silicone shell keep it strong yet portable. Reduced neck and shoulder strain means longer, steadier sessions without fatigue.
Immersive Round Display
A 0.72" 1920 × 1200 AMOLED round display delivers a crisp, natural view that mimics traditional binocular optics. With a 60Hz refresh rate, image transitions remain smooth, even when tracking fast-moving targets providing a lifelike, lag-free experience.
F1.1 Large-Aperture Lens
The advanced F1.1 50mm lens delivers excellent brightness and contrast, ideal for night operations and low-visibility conditions. Designed to maximise light intake and image clarity, it provides enhanced definition and sharpness even in fog, shadow, or heavy cover.
High-Sensitivity Thermal Core
Featuring a self-developed 640×512 sensor and NETD ≤15mK, the Quest H50R detects the smallest heat differences for detailed, accurate imaging, even at long range or through heavy cover.
Reality+ AI Image Enhancement
The Reality+AI algorithm uses deep neural networks to sharpen image detail and remove noise without over-smoothing. It preserves natural definition down to every strand of fur or blade of grass, creating a true-to-life thermal image that sets a new benchmark for clarity.
Key Specifications
- Objective Lens: 50mm (F1.1)
- Sensor: 640×512@12 µm
- NETD: ≤15mK
- Field of View: 8.8° × 7.0°
- Display: 1920 × 1200 AMOLED (0.72″ Round)
- Optical Magnification: 4x-32x
- Detection Range: Up to 2600m
- Battery: Replaceable 18650 Li-ion
- Dimensions: 175 × 138 × 66mm
- Weight: ≈ 700g
- Construction: Magnesium alloy frame with silicone shell
